Robotics 2010 Camp
Day 4 -- June 17, 2010
MSU Afternoon Group
Today, the campers were introduced to the engineering and
programming concepts of light sensors and touch sensors. In the "Color
Kicker" activity, campers were challenged to design, build, and
program a device to "kick" a red ball in one direction and a blue ball
in another direction. This device used the light sensor to determine the color
of the ball, is the basis of many robotic selection devices used in
manufacturing and industrial pick-and-place applications. Next, the campers were
introduced to "River Rising," a
river flooding scenario in which a semi-tractor trailer loaded with drums of oil
was perched precariously close to a river bank that was close to collapse. The
challenge was to design, build, and program a robotic vehicle to retrieve the
trailer, using only the touch sensor for input. This problem called upon the
campers to work together and come up with their very best design ideas.
Teams learned a variety of skills all in preparation for the Robot Derby events
to be held on Day Five. Parents, grandparents, family, and friends - you are all welcome to join the
Derby Day events after our morning break at 2:30 so your camper can demonstrate
some of his or her projects. Bring your cameras and be ready to experience
MSU Robotics Camp 2010 at
its finest!
