Robotics 2004 Camp
Day 4, July 1, 2004
MSU Morning Group
Today, the campers were introduced to the engineering and programming of
touch sensors. The touch sensors allowed campers to bump their robots into
objects to trigger steps in their robot programs.
Bump-N-Go (Choca y va),
Bump-N-Steer (Choca y da una vuelta), Touch Sensor Trolley Car
(Choca y va con un trole)
and the Chain Drive Madness (La Cadena de locura). were the challenging events campers used
their construction and programming skills to complete today. The
Bump-N-Go design challenge gave the campers the chance to construct a
vehicle from a construction card that will strike a barrier, trigger the touch
sensor, reverse direction and stop in a box. Touch
Sensor Trolley
Car required touch sensors to trigger different parts of their
program to make their trolley carry passengers safely across a gorge.
Chain Drive Madness was the design
challenge of the day. Campers had to construct a robot that would navigate a
chain using touch sensors to change the different steps of their program.
Teams learned a variety of skills all in preparation for the Robot Derby events
to be held on Day Five. Parents, grandparents, family, and friends, you are all welcome to join the
Derby Day events after our morning break at 10:30 so your camper can demonstrate
some of his or her projects. Bring your cameras and be ready to experience
MSU Robotics Camp 2004 at
its finest!
